Kioti DK6020SEH

Product Description

Feature	Specification
Engine	3-cylinder diesel — model 3HT-TH4C
Gross Power	57.70 hp (43 kW)
Displacement	111.40 cu in / 1,826 cc
Rated RPM	2,600 rpm
Fuel Capacity	12.70 gal (48 L)
Transmission	Hydrostatic (HST), 3-range / infinite speeds / hydrostatic shuttle
Max Travel Speed	Up to ~18.5 mph forward / ~20.8 mph reverse
PTO	Independent rear PTO — 540 rpm; optional mid-PTO 2,000 rpm
Hydraulic System	Gear pump, ~16.50 gpm (62.4 L/min) total flow
Rear 3-Point Hitch Lift Capacity	2,716 lb (1,232 kg), Category 2 hitch, position control
Brakes / Drive-Train	Wet-disc brakes, 4WD with rear diff-lock available
Dimensions (with hitch)	Length: ~126 in (3,202 mm); Width: ~62.8 in (1,596 mm); Ground clearance: ~14.5 in (368 mm)
Operating Weight	~3,523 lb (1,598 kg)
