Kioti CK4020SE

Product Description

Feature	Specification
Engine	3‑cyl diesel, Daedong model 3H‑TM4B
Gross Power	39.6 hp / 29.5 kW
Rated Speed (RPM)	2,600 rpm
Displacement	111.4 cu in / 1,826 cc
Fuel Capacity	9.0 gal / 34 L
Transmission	12-speed synchro shuttle
Drive Type	4WD, power steering, wet disc brakes
PTO	Independent rear PTO (540 rpm); optional mid PTO (2,000 rpm)
Hydraulic Pump Flow	11.73 gpm / 44.4 L/min (open‑centre)
Rear 3‑Point Hitch Lift Capacity	~1,631 lb / 740 kg, Category I, position control
Ground Clearance	13.4 in / 340 mm
Dimensions (L × W × H)	120.9″ × 54.5″ × 92.9″
Weight	~2,906 lb (1,318 kg)
