Kioti CX2510

Product Description

Feature	Specification
Engine	3-cyl, liquid-cooled diesel, Kioti 3A165LWH-U2
Gross Power	24.5 hp (18.3 kW)
Displacement	87 cu in (1,647 cc)
Fuel Capacity	6.6 gal (25 L)
Transmission Options	6F / 2R manual Also available: Infinite/2-range Hydrostatic (HST)
Max Speed (Manual)	~10.80 mph forward, ~7.40 mph reverse
PTO	Transmission-driven PTO: 19.3 hp (14.4 kW) Rear PTO: 540 rpm, optional Mid PTO: 2,000 rpm
Brakes / Clutch	Wet disc brakes; dry single-stage clutch
Hydraulic System	Gear pump; 11.3 gpm (42.9 L/min)
3-Point Hitch Lift	~1,203 lb (546 kg) at 24″ behind hitch; Category I, position control
Dimensions (L × W × H)	109.08″ × 49.40″ × 82.80″ (2790 mm × 1256 mm × 2103 mm)
Weight	~2,308 lb (1,047 kg)
