Kioti CS2220H

Product Description

Feature	Specification
Engine	3-cyl liquid-cooled diesel, Kioti 3C100LWH-U3
Gross Power	21 hp / 15.6 kW
Displacement	61.5 cu in (1,007 cc)
Fuel Capacity	6.70 gal / 25.5 L
Transmission	Hydrostatic (HST), 2-range (Hi / Lo)
Drive Type	4WD with standard differential lock
Hydraulic Pump Flow	~ 7 gpm / 26.4 L/min
3-Point Hitch Lift Capacity	700 lb / ~318 kg, Category I
PTO	Independent rear PTO (540 rpm) + mid PTO ~2,200 rpm
Travel Speed	Forward: up to ~9.57 mph; Reverse: ~6.60 mph
Dimensions (L × W × H)	~ 99.3 in × 45.9 in × 88 in
Weight	~1,554 lb (705 kg)
