| Engine |
16" Bar, .3/8" Pitch, .050" Gauge
SKU: 966 99 72‑36
|
| Chain speed at max power |
62.3 fts |
| Cylinder displacement |
35.2 cm³ |
|
Output shaft power1
|
2.01 hp |
| Torque, max. |
1.57 Nm |
| Torque, max. at rpm |
7,500 rpm |
| Clutch engagement speed (±120) |
4,700 rpm |
| Electrode gap |
0.03 in |
| Idling speed |
2,900 rpm |
| Ignition module air gap |
0.02 in |
| Maximum power speed |
10,000 rpm |
| Oil pump capacity, max |
9 ml/min |
| Oil pump capacity, min |
3 ml/min |
| Oil pump type |
Automatic |
| Spark Plug |
NGK CMR6H |
| Equipment |
|
| Recommended bar length, min |
12 in |
| Pitch |
3/8" mini |
| Recommended bar length, max |
14 in |
| Chain type |
H37 |
| Bar length |
40 cm |
| Bar length (inch) |
16 in |
| Sprocket type |
Spur 6 |
| Gauge |
.050" |
| Dimensions |
|
| Weight (excl. cutting equipment) |
7.5 lbs |
| Sound and noise |
|
| Sound pressure level at operators ear |
103 dB(A) |
| Sound power level, guaranteed (LWA) |
114 dB(A) |
| Sound power level, measured |
112 dB(A) |
| Vibration |
|
| Equivalent vibration level (ahv, eq) rear handle |
3.9 m/s² |
| Equivalent vibration level (ahv, eq) front handle |
3.6 m/s² |
| Lubricant |
|
| Oil tank volume |
0.36 US pint |
| Lubricant type (Engine) |
Husqvarna 2 stroke or equiv. at 50:1 |
| Emission |
|
|
Exhaust emissions (CO₂ EU V)2
|
860 g/kWh |
