Diamond R Equipment

Wacker Neuson ST37

Product Description

Feature	Specification
Engine	4-cyl diesel, model KDI2504TCR, 151.5 cu in
Gross Power	73.8 hp / ~ 74 hp
Rated Engine Speed	2,600 rpm
Operating Weight (approx.)	~ 9,014.7 lb
Rated Operating Capacity (50% Tip Load)	~ 3,699 lb (≈ 1,678 kg)
Tipping Load	~ 7,400.9 lb (≈ 3,357 kg)
Breakout Force (Bucket)	~ 5,300 lbf
Hydraulic Flow (Standard Aux.)	23.0 GPM (87 L/min) — optional high flow 33.1 GPM (125.2 L/min)
Fuel Tank Capacity	32.8 gal (124 L)
Tracks / Ground Pressure	Standard track, ~ 5.8 psi ground pressure
Travel Speed	Two-speed travel: ~ 5.8 m/h & 8.8 m/h (≈ 9.3 / 14.1 km/h) depending on gear
Dimensions (w/ Bucket)	Length ~ 136.1 in; Height to top of ROPS ~ 82.8 in; Width (without bucket) ~ 72 in
