Kioti CK4020H

Product Description

Feature	Specification
Engine	3‑cyl diesel, model 3H‑TM4A
Gross Power	~ 39.6 hp / 29.5 kW
Displacement	111.40 cu in (1,826 cc)
Rated Speed (RPM)	2,600 rpm
Fuel Capacity	9.0 gal (34 L)
Transmission	Hydrostatic (HST) with twin pedals
Max Travel Speed	– ~14.88 mph forward, ~10.41 mph reverse (3‑range HST)
PTO	Live rear PTO, 540 rpm; optional mid PTO ~2,000 rpm
PTO Power	~33.3 hp (at rated engine speed)
Hydraulic Pump Flow	~11.70 gpm (44.4 L/min)
Rear 3‑Point Hitch Lift Capacity	1,631 lb / 740 kg, Category I, position control
Ground Clearance	13.4 in / 340 mm
Dimensions (L × W × H)	120.90″ × 54.50″ × 92.90
Weight	~2,734 lb / 1,240 kg
