Wacker Neuson Compact Light Tower LTT4
Compact light tower w/4-320w LED lights and a adjustable vertical mast, Duplex outlets
The LTT4 light towers offer a smaller footprint, and the long-lasting LED's deliver exceptional light coverage for a variety of applications where temporary lighting is needed. The units are equipped with auxiliary power which adds to the versatility of these machines.
LED Lights
Rated to last the life of the machine, the durable LED lights eliminate frequent bulb replacement expense, reducing the total cost of ownership
Four 320 Watt LED lights provide a total of 192,000 Lumens instantaneously and increase uptime by eliminating warm-up and cool-down periods
Efficient LED lights extend the machine's run time and reducing overall operating costs
Programmable Controller
Easy to use controller
Allows for customizable start up and shut-downs as well as monitors fuel usage and alarms when fuel is low
Heated display for cold weather conditions
Compact Design
Foldable tongue minimizes the machine footprint for shipping and storage
Fork pockets and lifting eye make it easy to load, unload, and place machine
Compact design allows for 22 machines to fit on a 48 ft trailer and 24 machines on a 53 ft. trailer
Standard Auxiliary Power
2700 Watts to 4700 Watts auxiliary power allows for the use of power tools and other equipment while the lights are running
Telescopic Vertical Mast
The compact telescopic vertical mast design reduces storage and transportation area, improving logistics efficiencies.
Manual, dual handle winch enables quick raising and lowering of mast.
Extended 1,000 Hour Service Interval
1,000 hour oil change interval means more time working and less time servicing, reducing total cost of ownership.
GENERATOR
Metric
Imperial
Generator Manufacturer
Mecc Alte
Mecc Alte
Voltage accuracy
10,0 %
10,0 %
Gen. Rating 1~ (Cont.) [kW]
4,5 kW
4,5 kW
Output frequency
60 Hz
60 Hz
OPERATING FLUIDS
Metric
Imperial
Run Time (Lights only)
211,1 std
211,1 std
Fuel consumption (Lights only)
0,9 L/Std
0,2 GPH US
LIGHTING - OUTPUT DETAILS
Metric
Imperial
Coverage area
670 m2
7.211,9 ft2
Illuminance
54 Lux
5,0 fc
ENGINE
Metric
Imperial
Cylinder
2
2
Cooling
Water-cooling
Water-cooling
Exhaust-gas limit
EPA Tier 4 final
EPA Tier 4 final
Engine Manufacturer
Kohler
Kohler
Cylinder capacity
686 cm3
41,9 Inch3
Tank capacity
198,40 l
52,4 gal US
Operating Engine speed
1.800 1/min
1.800 1/min
Effective power
5,5 kW
7,4 hp
Engine type
Diesel engine
Diesel engine
ELECTRICAL SYSTEM
Metric
Imperial
Lighting appliances
320W (LED)
320W (LED)
Bulb power
320 W
320 W
MECHANICAL DETAILS
Metric
Imperial
Operating weight
680,0 kg
1.499,1 lb
Length
2.563 mm
100,9 "
Height
2.548 mm
100,3 "
Mast height max.
7,0 m
23,0 Foot
Width
1.207 mm
47,5 "
